Responsive 4G up to 300 Mbps Download
Responsive 4G up to 300 Mbps Download
A Powerful Connectivity Hub
Reponsive AC1200 Wi-Fi
Full Gigabit Ports
Abundant Features for Detailed Tweaking
Online Redundancy
Band Lock
TTL Settings
DNS Encryption
Easy Setup and Versatile Management
Plug and Play
Schedule and Filtering
VPN Server and Client
Fast Roaming
Cudy App
Cudy App
Model Version | ||
---|---|---|
Model Version | LT700E 1.0 | |
CPU | ||
CPU | Chipset | MT7621 |
CPU Details | 880 MHz Dual-Core, MIPS1004Kc | |
Memory/Storage | ||
Memory/Storage | Flash/ROM | 16 MB (128 Mbit) NOR |
DDR/RAM | 128 MB (1 Gbit) DDR3 | |
Cellular | ||
Cellular | Cellular Standards | 4G LTE Cat. 6 |
Cellular Antennas | 2× Internal | |
SIM Options | 1× Nano SIM Slot | |
Available Versions | EU, US | |
EU Version Cellular | ||
EU Version Cellular | Suitable Region | Europe, Middle East, Africa, Australia, Brazil |
Max DL Speed | 300 Mbps (LTE-FDD), 220 Mbps (LTE-TDD) | |
Max UL Speed | 50 Mbps (LTE-FDD), 30 Mbps (LTE-TDD) | |
Advanced | DL 2CA, DL 2×2 MIMO | |
Cellular Bands |
LTE-FDD: B1/3/5/7/8/20/28/32 LTE-TDD: B38/40/41 WCDMA: B1/5/8 |
|
US Version Cellular | ||
US Version Cellular | Suitable Region | United States, Canada |
Max DL Speed | 300 Mbps (LTE-FDD), 226 Mbps (LTE-TDD) | |
Max UL Speed | 50 Mbps (LTE-FDD), 28 Mbps (LTE-TDD) | |
Advanced | DL 2CA, DL 4×4 MIMO | |
Cellular Bands |
LTE-FDD: B2/4/5/7/12/13/14/25/26/29/30/66/71 LTE-TDD: B41/48 |
|
Wireless | ||
Wireless | 5 GHz Wi-Fi Speed | 867 Mbps |
2.4 GHz Wi-Fi Speed | 300 Mbps | |
5 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
Wi-Fi Antennas | 2× Internal | |
5 GHz Antenna Gain Max | 4.99 dBi | |
2.4 GHz Antenna Gain Max | 5.18 dBi | |
Beamforming | True | |
FEM or PA/LNA |
|
|
Range Performance |
Max: 170 m (558 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. |
|
Wall Performance |
One wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'') |
|
Interfaces | ||
Interfaces | Physical Buttons |
|
Gigabit RJ45 Ports | 4 | |
Ethernet Notes | One port supports WAN/LAN configuration, and the rest are LAN ports | |
LED |
|
|
Power Input | DC Jack | |
Power | ||
Power | Power Methods | DC |
DC | 12V 1.5A | |
Power Adapter |
Input: 100 ~ 240 V, 50/60 Hz AC Output: 48V 1.5A DC |
|
Max Power Consumption (W) | 11.2W | |
Idle Power Consumption (W) | 3.6W | |
Reliability | ||
Reliability | ESD Contact Protection | 4kV |
ESD Air Protection | 8kV | |
Environment | Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) | |
Certifications | ||
Certifications | FCC, CE | |
Mechanical | ||
Mechanical | Dimension |
190×50×148.8 mm 7.48×1.97×5.86 inches |
Product Weight | 300 g (10.58 oz.) | |
Installation | Desktop | |
Package Content | ||
Package Content |
|
|
Ordering Information | ||
Ordering Information | Retail Package Weight | EU / US: 595 g (20.99 oz.) |
Retail Package Dimension |
270×58×168 mm 10.63×2.28×6.61 inches |
|
Units per Carton | 20 | |
Carton Net Weight | EU / US: 11.9 kg (26.23 lbs) | |
Carton Gross Weight | EU / US: 12.8 kg (28.22 lbs) | |
Carton Dimension |
55.8×31.7×36.3 cm 21.97×12.48×14.29 inches |
Model Version | ||
---|---|---|
Model Version | LT700E 1.0 | |
Wireless | ||
Wireless | Wi-Fi Standards | Wi-Fi 5 |
Max Wi-Fi Modulation | 256-QAM | |
Wi-Fi Efficiency | MU-MIMO | |
Wi-Fi Efficiency Note | MU-MIMO available on 5 GHz | |
Max Capacity | 128 | |
Recommended Client Upper Limit | 50 | |
Max Wi-Fi Channel Width | 80 MHz | |
Wi-Fi Security | WPA/WPA2/WPA3 | |
Guest Network | 2.4 GHz, 5 GHz | |
WPS | True | |
General | ||
General | Operation Modes |
|
Mesh | Cudy Mesh Main | |
Mesh Backhaul |
|
|
Cellular APN |
|
|
Cellular Mode |
|
|
WAN Mode |
|
|
Internet Failover Sequence |
|
|
Network | ||
Network | QoS | Per-User Rate Limiting |
DHCP |
|
|
IP Versions | IPv4/IPv6 | |
IPv6 Protocols |
|
|
IPTV/VLAN |
|
|
TTL Customization |
|
|
IGMP |
|
|
Forwarding |
|
|
Firewall |
|
|
Application Layer Gateway |
|
|
Utilities | ||
Utilities | VPN Server |
|
VPN Client |
|
|
DNS Options |
|
|
DNS over TLS Providers |
|
|
Wake on LAN | True | |
Online Detection | True | |
Management | ||
Management | All Devices Management |
|
Per-Devices Management |
|
|
Content Management |
|
|
System | ||
System | Local Control Method |
|
Remote Control Method |
|
|
Firmware Upgrade |
|
|
Diagnostic Tools |
|
|
Languages |
|
|
Reliability |
|
|
Dashboard | ||
Dashboard | Panel |
|
Charts |
|
- 4×4 MIMO is available on the US version. 2×2 MIMO is avaialble on the EU version.
- Actual wireless data throughput will vary as a result of network conditions, client limitations, and environmental factors including building layout, obstacles, and client location.
