規劃
| 型號版本 | ||
|---|---|---|
| 型號版本 | GS1005P 2.0 | |
| Interfaces | ||
| Interfaces | Gigabit RJ45 Ports | 5 |
| Gigabit RJ45 PoE Ports | #1~#4 | |
| Max Power on a Single PoE Port | 30W | |
| PoE Port Notes | The PoE ports comply with IEEE 802.3at/af standards. | |
| Intelligent Power Management (PoE) | Automatically disconnect the lastly powered device when power exceeds budget. | |
| Extend Mode Ports | #1~#4 | |
| VLAN Mode Ports | #1~#4 | |
| LED |
|
|
| Power Input | DC Jack | |
| Physical Buttons |
|
|
| Physical Buttons Note | The PoE Watchdog will attempt to reboot the plugged-in clients that have been inactive for 5 minutes. Do not turn it on for clients with online auto-upgrade feature. | |
| Performance | ||
| Performance | Copper Speed and Distance |
|
| Copper Speed and Distance Note | 250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated. | |
| MAC Address Table | 2048 | |
| Max Switching Capacity | 10 Gbps | |
| Max Forwarding Rate | 7.44 Mpps | |
| Jumbo Frame | 15 KB | |
| Packet Buffer | 3 Mbit | |
| Power | ||
| Power | Power Methods | DC |
| DC | 54V 1.11A | |
| Power Adapter |
Input: 100 V - 240 V, 50 Hz Output: 54 V, 1.11 A |
|
| Power Supply | 60W | |
| Max Power Excluding PoE | 5W | |
| Switching | ||
| Switching | 802.3 Protocols |
|
| L2 Features |
|
|
| Reliability | ||
| Reliability | Grounding Methods | Three-Prong Plug |
| EMS |
IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV |
|
| Environment |
Operating Temperature: 0~40 ℃ (32~104 ℉) Storage Temperature: -40~70℃ (-40~158 ℉) Operating Humidity: 10~90% non-condensing Storage Humidity: 10~95% non-condensing |
|
| Mechanical | ||
| Mechanical | Dimension |
119×85×28 mm 4.69×3.35×1.1 inches |
| Product Weight | 253.0 g (8.92 oz.) | |
| Casing Material | Metal | |
| Installation |
|
|
| Package Content | ||
| Package Content |
|
|
| Ordering Information | ||
| Ordering Information | Retail Package Dimension |
165×123×60 mm 6.5×4.84×2.36 inches |
| Retail Package Weight | EU: 890.0 g (31.39 oz.) | |
| Carton Net Weight | EU: 17.8 kg (39.24 lbs) | |
| Carton Gross Weight | EU: 18.5 kg (40.79 lbs) | |
| Carton Dimension |
37.6×26.4×33.8 cm 14.8×10.39×13.31 inches |
|
