AX3000 86mm Wall-Plate Wi-Fi 6 Access Point

Name: AX3000 86mm Wall-Plate Wi-Fi 6 Access Point, AP3000E Wall 1.0
Brand: Cudy

AX3000 86mm Wall-Plate Wi-Fi 6 Access Point, AP3000E Wall 1.0

Product variants

A compact wall-mounted WiFi 6 AP with two Gigabit ports ideal for single-room coverage in hospitality environments.

Model Version
Model Version	AP3000E Wall 1.0
Wireless
Wireless	Wi-Fi Standards	Wi-Fi 6
	Max Wi-Fi Modulation	1024-QAM
	Wi-Fi Efficiency	OFDMA MU-MIMO BSS Color
	Max Capacity	256
	Recommended Client Upper Limit	100
	Max Wi-Fi Channel Width	160 MHz
	Wi-Fi Security	WPA/WPA2/WPA3
	Multi-SSID (Max Number)	8 SSIDs (Up to 4 SSIDs on each band)
General
General	Operation Modes	Access Point
	Mesh	Cudy Mesh
	Mesh Backhaul	Wireless Backhaul Wired Backhaul
	Multi-Band Backhaul	True
Network
Network	DHCP	Server
	IP Versions	IPv4
	IGMP	IGMP Snooping
Utilities
Utilities	Wake on LAN	True
Management
Management	All Devices Management	Wi-Fi Time Schedule
System
System	LED Control	True
	Local Control Method	Config Web Page App Control
	Remote Control Method	Config Page via HTTPS App Control
	Firmware Upgrade	Local Update App (Over the Air) Online Update
	Reliability	Timed Reboot Backup and Restore
	Diagnostic Tools	Diagnosis Ping Traceroute NSLookup System Log
	Languages	English Bengali Catalan Czech German Greek Spanish French Hebrew Croatian Hungarian Italian Japanese Khmer Korean Dutch Norwegian Polish Portuguese Romanian Russian Slovak Swedish Thai Turkish Ukrainian Vietnamese Simplified Chinese Traditional Chinese
Dashboard
Dashboard	Panel	Internet Status Mesh Status Devices Management LAN Status Wi-Fi Status DHCP Server Status System Version WISP Status Connected Devices
	Charts	Mesh Topology Wi-Fi Speed

Actual wireless data throughput will vary as a result of network conditions, client limitations, and environmental factors including building layout, obstacles, and client location.
The wireless coverage claim serves as a reference only. Coverage performance will vary due to environmental factors including building layout, obstacles, traffic volume and density, and device location. For optimal coverage, please place the device in a central location within the area requiring Wi-Fi.
Actual performance for multiple devices may be affected by the types of applications used, the total available bandwidth, and the capabilities of your devices. Connecting older Wi-Fi devices (legacy standards) may reduce overall efficiency. Using efficiency features requires compatible client devices that also support those features. Find more information about supported efficiency features in the software section of the Specs spreadsheet.
